FEATURES
1. Splay terminals allow for automatic insertion by IC insertion machine.
2. straight terminals are available for manual insertion.
3. Insert molding of terminals and ultrasonic welding improve flux proofness and enable flux washing in whole by top tape sealing.
4. NDI series(raised actuafor)and NDIR series(recessed actuator)available for different purposes.
5. Double contacts offers high reliability.
6. Vapor phase solderable, IR-reflow solderable. Terminal plating by gold give execellent results when soldering.
Terminal plating: Tin/lead available too.
MATERLALS
BASE & COVER: UL94V-0 PPS High Temp.
Thermoplastic.
Color: white.
TERMINAL: Brass.
CONTACT PLATING: Gold plating over nickel.
TERMINAL PLATING: Gold (or Tin/lead available)
